Pilz 570 Rope Pull Switch 50 m, 2 NO/2 NC

RS庫存編號:: 313-761
製造零件編號:: 570303
製造商:: Pilz

Pilz 570 Rope Pull Switch 50 m, 2 NO/2 NC

小計（1 件）*

TWD10,872.00

(不含稅)

TWD11,415.60

訂單超過 $1,300.00 免費送貨

暫時缺貨

從 2026年7月07日發貨

**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。

單位	每單位
1 +	TWD10,872.00

* 參考價格

RS庫存編號:: 313-761
製造零件編號:: 570303
製造商:: Pilz

規格

產品概覽和技術數據資料表

法例與合規

產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	Pilz
	Product Type	Rope Pull Switch
	Contact Configuration	2 NO/2 NC
	Series	570
	Contact Current	3A
	Minimum Operating Temperature	-25°C
	E-Stop Button	Yes
	Contact AC Voltage	240V ac
	Maximum Operating Temperature	70°C
	Housing Material	Polyamide
	Length	50m
	Width	294mm
	Standards/Approvals	CE, UKCA, CCSAUS, EAC, BG
	Depth	42.5mm
	Hazardous Area Certification	No

	選取全部
	品牌 Pilz
	Product Type Rope Pull Switch
	Contact Configuration 2 NO/2 NC
	Series 570
	Contact Current 3A
	Minimum Operating Temperature -25°C
	E-Stop Button Yes
	Contact AC Voltage 240V ac
	Maximum Operating Temperature 70°C
	Housing Material Polyamide
	Length 50m
	Width 294mm
	Standards/Approvals CE, UKCA, CCSAUS, EAC, BG
	Depth 42.5mm
	Hazardous Area Certification No

Datasheet - 570303

豁免

The Pilz rope pull switch, featuring an emergency stop (E-STOP) pushbutton, comes with a plastic housing and includes 2 normally closed (NC) contacts and 2 normally open (NO) contacts. It offers a maximum spring force of 175 N and supports a maximum current of 3 A for AC15 safety contacts. The environmental temperature range is -25°C to 70°C. The lower section of the housing is made of PA (Polyamide), ensuring robustness and reliability in various conditions.

CE approved

RoHS compliant

Zn die cast actuator
