MEAN WELL LED Driver, 36V Output, 36 W Output, 1A
- RS庫存編號:
- 660-0283
- Distrelec 貨號:
- 110-43-407
- 製造零件編號:
- LPV-35-36
- 製造商:
- MEAN WELL
可享批量折扣
小計（1 件）*
TWD400.00
(不含稅)
TWD420.00
(含稅)
庫存資訊目前無法存取 - 請稍後再回來查看
單位 | 每單位 |
|---|---|
| 1 - 4 | TWD400.00 |
| 5 - 9 | TWD392.00 |
| 10 - 24 | TWD385.00 |
| 25 - 49 | TWD376.00 |
| 50 + | TWD369.00 |
* 參考價格
- RS庫存編號:
- 660-0283
- Distrelec 貨號:
- 110-43-407
- 製造零件編號:
- LPV-35-36
- 製造商:
- MEAN WELL
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | MEAN WELL | |
| Output Voltage | 36V | |
| Product Type | LED Driver | |
| Maximum Output Power | 36W | |
| Input Voltage | 264, 90V ac | |
| Mount Type | Panel | |
| Sub Type | LED Driver | |
| Terminal Type | Wire | |
| Input Voltage Type | AC | |
| IP Rating | IP67 | |
| LED Voltage | 264, 90V ac | |
| Driver Current | 1A | |
| Operating Modes | Constant Voltage | |
| Standards/Approvals | CB, CSA, EN, IEC, LPS, UL, CE | |
| Series | LPV-35 | |
| Number of Outputs | 1 | |
| Configuration | Enclosed | |
| Primary Type | AC-DC | |
| Power Dissipation | 36W | |
| 選取全部 | ||
|---|---|---|
品牌 MEAN WELL | ||
Output Voltage 36V | ||
Product Type LED Driver | ||
Maximum Output Power 36W | ||
Input Voltage 264, 90V ac | ||
Mount Type Panel | ||
Sub Type LED Driver | ||
Terminal Type Wire | ||
Input Voltage Type AC | ||
IP Rating IP67 | ||
LED Voltage 264, 90V ac | ||
Driver Current 1A | ||
Operating Modes Constant Voltage | ||
Standards/Approvals CB, CSA, EN, IEC, LPS, UL, CE | ||
Series LPV-35 | ||
Number of Outputs 1 | ||
Configuration Enclosed | ||
Primary Type AC-DC | ||
Power Dissipation 36W | ||
RS - 35W Waterproof (IP67) SMPSU
External switch mode epoxy encapsulated IP67 rated power supplies
High efficiency, long life and high reliability
Designed for indoor or outdoor installations
Suitable for LED lighting and moving sign applications
Withstands 300Vac surge input for 5 seconds
100% full load burn-in test
Fully regulated output
Short circuit, over-current, over-voltage protection
600mm un-terminated, 2-core 18AWG input lead
600mm un-terminated, 2-core 16AWG output lead
UL1310 Class 2 power unit, pass LPS
EMC compliance to EN 55022 Class B
Harmonic current compliance to EN 61000-3-2,-3
Stk nos 660-0274, 660-0277, 660-0271, 660-0280, 660-0283 are constant voltage power supplies
Stk nos 660-0287, 660-0296 and 660-0299 are constant current power supplies
Note
For Industrial Use Only, not in scope of Regulation (EC) No 125/2009.
Power derates above 65°C (5Vdc version derates above 55°C).
MTBF to MIL-HDBK-217F.
Power derates above 65°C (5Vdc version derates above 55°C).
MTBF to MIL-HDBK-217F.
Standards
TUV EN 60950-1, EN 61347-2-13, UL 1310 Class 2, CAN/CSA C22.2 No. 223-M91
