Siemens RCCB, 40A, 4 Pole, 300mA, Type A
- RS庫存編號:
- 124-7741
- 製造零件編號:
- 5SV3644-6
- 製造商:
- Siemens
查看所有RCCBs
- RS庫存編號:
- 124-7741
- 製造零件編號:
- 5SV3644-6
- 製造商:
- Siemens
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- DE
產品詳細資訊
Series 5SV3 RCCBs
From Siemens the 5SV3 series are RCCBs suitable for personnel and fire protection. Available in 2 or 4 pole versions, each breaker can be DIN rail mounted. 5SV3 RCCBs offer highly reliable performance and excellent quality.
Residual current operated circuit breaker for personnel and fire protection
Silicone free
2 or 4 pole versions available
Instant tripping, surge current withstand capability >1kA
DIN rail mounting
Equipment life span: >10,000 switching cycles
Enclosure: IP20
Ambient temperature: -25→+45 °C
Break time - instantaneous
Protection against residual currents
Easy and safe installation
Silicone free
2 or 4 pole versions available
Instant tripping, surge current withstand capability >1kA
DIN rail mounting
Equipment life span: >10,000 switching cycles
Enclosure: IP20
Ambient temperature: -25→+45 °C
Break time - instantaneous
Protection against residual currents
Easy and safe installation
規格
| 屬性 | 值 |
| Circuit Breaker Type | RCCB |
| Current Rating | 40A |
| Number of Poles | 4 |
| Range | Sentron |
| Trip Sensitivity | 300mA |
| Tripping Characteristics | Type A |
| Series | 5SV3 |
| Break Time | Instantaneous |
| Overall Length | 71.8mm |
| Terminal Contact Type | Screw |
| Reset Actuator Type | Toggle Switch |
| Overall Dimensions | 71.8 x 77.2 x 89.8mm |
| Overall Depth | 89.8mm |
| Overall Width | 77.2mm |
| Rated AC Voltage | 400V |
| Mounting Style | DIN Rail Mount |
