WAGO 734 Series Pluggable Terminal Block, 12-Contact, 3.5 mm Pitch, 1 Row, 734-112/037-000

查看所有Pluggable Terminal Blocks
暫時缺貨
RS庫存編號:
891-9905
製造零件編號:
734-112/037-000
製造商:
WAGO
透過選取一個或多個屬性來查找類似產品。
選取全部

品牌

WAGO

Product Type

Pluggable Terminal Block

Number of Contacts

12

Pitch

3.5mm

Number of Rows

1

Current

10A

Housing Material

Polyamide

Connector Gender

Female

Minimum Wire Size AWG

28 AWG

Maximum Wire Size AWG

14 AWG

Orientation

Straight

Colour

Light Grey

Wire Connection Method

Cage Clamp

Voltage

160 V

Depth

18.6mm

Width

53.8 mm

Series

734

Standards/Approvals

No

COO (Country of Origin):
DE

WAGO Pluggable Terminal Block, 10A Current Rating, 3.5mm Pitch - MCS Mini Series - 734-112/037-000


Link up your cables and PCBs with this pluggable terminal block from WAGO. It has a 12-contact configuration, meaning that it can control 12 circuits simultaneously. The unit has compact dimensions of 13.4 (H) x 53.8 (W) x 18.6mm (D) to maximise space on your board. A rated surge voltage of 2.5kV means it can hold its own against sudden power spikes. The PA housing stands up to wear and impact, giving you long-term performance in harsh industrial environments.

Features & Benefits


• Single-row design to help keep your wiring setup organised

• Screw termination type for convenient and secure installation with just a screwdriver

• Accommodates wires ranging in size between 28 and 14AWG for flexibility

• Light weight of just 9.6g to minimise strain on your setup

Applications


• Bottling plants

• Robotics and automation

• Process and packaging industry

Is this component flame-resistant?


Yes, the block has self-extinguishing properties, so it stops burning in 10 seconds or less. This helps to reduce the spread of flames in the event of a fire for added safety.
