Inventronics IP20 1 Output LED Driver, 20V, 51 V, 72 W, 1400mA, 600 mA Non-Dimmable LED Driver
- RS庫存編號:
- 236-8676
- Distrelec 貨號:
- 303-72-926
- 製造零件編號:
- OT-FIT-75/220-240/1A4-NFC-L
- 製造商:
- Inventronics
可享批量折扣
查看批量定價選項小計（1 件）*
TWD1,176.00
(不含稅)
TWD1,234.80
(含稅)
訂單超過 $1,300.00 免費送貨
有庫存
- 10 件準備從其他地點送貨
**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。
單位 | 每單位 |
|---|---|
| 1 - 4 | TWD1,176.00 |
| 5 - 9 | TWD1,155.00 |
| 10 - 24 | TWD1,136.00 |
| 25 - 49 | TWD1,115.00 |
| 50 + | TWD1,094.00 |
* 參考價格
- RS庫存編號:
- 236-8676
- Distrelec 貨號:
- 303-72-926
- 製造零件編號:
- OT-FIT-75/220-240/1A4-NFC-L
- 製造商:
- Inventronics
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | Inventronics | |
| Product Type | LED Driver | |
| Output Voltage | 20, 51V | |
| Maximum Output Power | 72W | |
| Input Voltage | 220, 240V | |
| Mount Type | Screw | |
| Sub Type | LED Driver | |
| Dimming Operation | Non-Dimmable | |
| Terminal Type | Push-in | |
| Input Voltage Type | AC/DC | |
| IP Rating | IP20 | |
| Driver Current | 1400, 600mA | |
| LED Voltage | 20, 51V | |
| Operating Modes | Constant Current | |
| Series | OT FIT | |
| Number of Outputs | 1 | |
| Standards/Approvals | RCM, EAC, CE, CCC, BIS, VDE-ENEC | |
| Configuration | Enclosed | |
| Power Dissipation | 7W | |
| Primary Type | AC-DC | |
| 選取全部 | ||
|---|---|---|
品牌 Inventronics | ||
Product Type LED Driver | ||
Output Voltage 20, 51V | ||
Maximum Output Power 72W | ||
Input Voltage 220, 240V | ||
Mount Type Screw | ||
Sub Type LED Driver | ||
Dimming Operation Non-Dimmable | ||
Terminal Type Push-in | ||
Input Voltage Type AC/DC | ||
IP Rating IP20 | ||
Driver Current 1400, 600mA | ||
LED Voltage 20, 51V | ||
Operating Modes Constant Current | ||
Series OT FIT | ||
Number of Outputs 1 | ||
Standards/Approvals RCM, EAC, CE, CCC, BIS, VDE-ENEC | ||
Configuration Enclosed | ||
Power Dissipation 7W | ||
Primary Type AC-DC | ||
- COO (Country of Origin):
- CN
The Osram's Linear / Area Constant Current is Non dimmable forward voltage LED light source within the defined operating window of the control gear in all operating conditions including dimming if applicable.
Flexible and future-proof current setting via NFC (Near Field Communication)
Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
Fulfilling SVM (≤ 0.4) and PsT (≤ 1.0) standards
Type of protection IP20
