Festo, 100kg 100 mm, 8022565 1110mm/s
- RS庫存編號:
- 202-9662
- Distrelec 貨號:
- 301-68-727
- 製造零件編號:
- ESBF-BS-32-100-10P
- 製造商:
- Festo
小計（1 件）*
TWD40,071.00
(不含稅)
TWD42,074.55
(含稅)
訂單超過 $1,300.00 免費送貨
製造商存貨
- 準備從 2026年10月06日 起發貨
**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。
單位 | 每單位 |
|---|---|
| 1 + | TWD40,071.00 |
* 參考價格
- RS庫存編號:
- 202-9662
- Distrelec 貨號:
- 301-68-727
- 製造零件編號:
- ESBF-BS-32-100-10P
- 製造商:
- Festo
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | Festo | |
| Product Type | Electrical Linear Actuator | |
| Maximum Load | 100kg | |
| Stroke Length | 100mm | |
| Maximum Speed | 1110mm/s | |
| Series | ESBF | |
| Motor Technology | Servo Motor, Stepper Motor | |
| Maximum Force | 115N | |
| Duty Cycle | 100% | |
| IP Rating | IP40 | |
| Spindle Type | Ball Screw | |
| Overall Length Closed | 32mm | |
| Piston Rod Thread | M10 x 1.25 | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | RoHS | |
| Model Number | 8022565 | |
| 選取全部 | ||
|---|---|---|
品牌 Festo | ||
Product Type Electrical Linear Actuator | ||
Maximum Load 100kg | ||
Stroke Length 100mm | ||
Maximum Speed 1110mm/s | ||
Series ESBF | ||
Motor Technology Servo Motor, Stepper Motor | ||
Maximum Force 115N | ||
Duty Cycle 100% | ||
IP Rating IP40 | ||
Spindle Type Ball Screw | ||
Overall Length Closed 32mm | ||
Piston Rod Thread M10 x 1.25 | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals RoHS | ||
Model Number 8022565 | ||
- COO (Country of Origin):
- DE
Festo ESBF Series Electric Linear Actuator, IP40, 100% Duty Cycle - ESBF-BS-32-100-10P, Numeric Part Number:8022565
This electric linear actuator is engineered for precise control in various automation applications. With a stroke length of 100mm, it meets industrial needs for exact positioning. The actuator features a durable design, ensuring compatibility with diverse environments, complemented by its corrosion resistance and compliance with relevant standards.
Features & Benefits
• Achieves high precision with a repetition accuracy of ±0.01mm
• Delivers a high feed force of up to 1000N
• Utilises a ball screw to promote efficient linear motion and minimise friction
• Offers optional mounting positions for versatile installation
• Suitable for food environments, adhering to industry standards
• Operates effectively within ambient temperatures of 0 to 60°C
Applications
• Employed in automated assembly processes requiring accurate movement
• Suitable for warehouse automation systems that demand consistent performance
• Utilised in packaging machines for precise material handling
• Applicable in laboratory equipment with controlled motion needs
• Ideal for conveyors in manufacturing that require uniform alignment
What type of motors are compatible with this actuator?
It operates with stepper motors and servo motors for enhanced control.
Can it be mounted in different orientations?
Yes, the actuator supports multiple mounting positions based on your needs.
What is the maximum allowable ambient temperature for operation?
It can operate efficiently in temperatures ranging from 0 to 60°C.
How does it handle precision in busy environments?
It offers a repetition accuracy of ±0.01mm, ensuring dependable movement.
Is this actuator suitable for use in moist environments?
Yes, it has a corrosion resistance class CRC 2 for moderate corrosion stress.
