Otto Toggle Switch, Panel Mount, SP4T, Solder Terminal, 28 V dc
- RS庫存編號:
- 433-3269
- 製造零件編號:
- T4-0122
- 製造商:
- Otto
可享批量折扣
小計（1 件）*
TWD4,243.00
(不含稅)
TWD4,455.15
(含稅)
訂單超過 $1,300.00 免費送貨
有庫存
- 1 件準備從其他地點送貨
- 加上 25 件從 2026年3月26日 起發貨
**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。
單位 | 每單位 |
|---|---|
| 1 - 24 | TWD4,243.00 |
| 25 + | TWD4,116.00 |
* 參考價格
- RS庫存編號:
- 433-3269
- 製造零件編號:
- T4-0122
- 製造商:
- Otto
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | Otto | |
| Contact Configuration | SP4T | |
| Product Type | Toggle Switch | |
| Switch Contact Current | 1 A | |
| Mount Type | Panel | |
| Terminal Type | Solder | |
| IP Rating | IP68S, IP64 | |
| Illuminated | No | |
| Contact DC Voltage | 28V dc | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 85°C | |
| Actuator Material | Thermoplastic | |
| Standards/Approvals | No | |
| Series | Mini-Trims | |
| Mechanical Life | 100000Cycles | |
| 選取全部 | ||
|---|---|---|
品牌 Otto | ||
Contact Configuration SP4T | ||
Product Type Toggle Switch | ||
Switch Contact Current 1 A | ||
Mount Type Panel | ||
Terminal Type Solder | ||
IP Rating IP68S, IP64 | ||
Illuminated No | ||
Contact DC Voltage 28V dc | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 85°C | ||
Actuator Material Thermoplastic | ||
Standards/Approvals No | ||
Series Mini-Trims | ||
Mechanical Life 100000Cycles | ||
不相容
Trim switches
Biased to centre off, there are four N/O contacts and one common connection
2 axis 4 way(Forward,Back,Left,Right)
Robust design with good tactile feel
2 actuator styles
Operating Temperature: -55°C to +85°C
Contact Rating:1A(Inductive) @ 28Vdc
