製造零件編號

WIKA G 1/4 MNPT Pressure Gauge, 50 mm, 250 bar

RS庫存編號:: 222-7633
製造零件編號:: 8904421
製造商:: WIKA

WIKA G 1/4 MNPT Pressure Gauge, 50 mm, 250 bar

小計（1 件）*

TWD3,145.00

(不含稅)

TWD3,302.25

訂單超過 $1,300.00 免費送貨

有庫存

2 件準備從其他地點送貨

**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。

單位	每單位
1 +	TWD3,145.00

* 參考價格

RS庫存編號:: 222-7633
製造零件編號:: 8904421
製造商:: WIKA

規格

產品概覽和技術數據資料表

法例與合規

產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	WIKA
	Product Type	Pressure Gauge
	Maximum Pressure Measurement	250bar
	Minimum Pressure Measurement	0bar
	Pressure Connection	Stainless Steel
	Connection Size	G 1/4
	Connection Type	MNPT
	Series	131.11
	Case Material	Stainless Steel
	Dial Size	50mm
	Connection Location	Bottom Entry
	Dial Colour	White
	Maximum Operating Temperature	60°C
	Standards/Approvals	EAC, CE

	選取全部
	品牌 WIKA
	Product Type Pressure Gauge
	Maximum Pressure Measurement 250bar
	Minimum Pressure Measurement 0bar
	Pressure Connection Stainless Steel
	Connection Size G 1/4
	Connection Type MNPT
	Series 131.11
	Case Material Stainless Steel
	Dial Size 50mm
	Connection Location Bottom Entry
	Dial Colour White
	Maximum Operating Temperature 60°C
	Standards/Approvals EAC, CE

Datasheet-8904421

豁免

The Wika compact model 131.11 bourdon tube pressure gauge is constructed with a case and wetted parts from stainless steel. The instrument meets the requirements of the international industry standard EN 837-1.The modular design enables a multitude of combinations of process connections, nominal sizes and scale ranges. Due to this high variance, the instrument is suitable for use in a wide range of applications within industry. Maximum pressure is 250 bar.

Case and wetted parts from stainless steel

Cost-effective and reliable

Scale ranges from 0 .. 0.6 to 0 … 1,000 bar

WIKA G 1/4 MNPT Pressure Gauge, 50 mm, 250 bar
