TECO Westinghouse SG3 Series Logic Module, Relay Output, 6-Input, Analogue Input

RS庫存編號:: 286-422
製造零件編號:: JPSG3-10KR-A
製造商:: TECO Westinghouse

TECO Westinghouse SG3 Series Logic Module, Relay Output, 6-Input, Analogue Input

小計（1 件）*

TWD6,336.00

(不含稅)

TWD6,652.80

訂單超過 $1,300.00 免費送貨

有庫存

2 件準備從其他地點送貨

**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。

單位	每單位
1 +	TWD6,336.00

* 參考價格

RS庫存編號:: 286-422
製造零件編號:: JPSG3-10KR-A
製造商:: TECO Westinghouse

規格

產品概覽和技術數據資料表

法例與合規

產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	TECO Westinghouse
	Product Type	Logic Module
	Series	SG3
	Number of Inputs	6
	Output Type	Relay
	Input Type	Analogue
	Number of Outputs	8
	Minimum Operating Temperature	-20°C
	Maximum Operating Temperature	50°C
	Width	126 mm
	Standards/Approvals	CE, IEC61000-6-4, UKCA, IEC61131-2, UL/Recognition
	Programming Language Used	FBD, Ladder Diagram (LD)
	Supply Voltage	100 → 240 V
	Communication Port Type	Ethernet
	Mount Type	DIN Rail, Direct
	Display Included	Yes
	Output Current	0.5A

	選取全部
	品牌 TECO Westinghouse
	Product Type Logic Module
	Series SG3
	Number of Inputs 6
	Output Type Relay
	Input Type Analogue
	Number of Outputs 8
	Minimum Operating Temperature -20°C
	Maximum Operating Temperature 50°C
	Width 126 mm
	Standards/Approvals CE, IEC61000-6-4, UKCA, IEC61131-2, UL/Recognition
	Programming Language Used FBD, Ladder Diagram (LD)
	Supply Voltage 100 → 240 V
	Communication Port Type Ethernet
	Mount Type DIN Rail, Direct
	Display Included Yes
	Output Current 0.5A

Datasheet - JPSG3-10KR-A

COO (Country of Origin):: CN

The TECO Westinghouse High performance Logic Relay comes with Ethernet communication. It offers extensive communication features with an integrated Ethernet interface. It provides efficient programming, remote monitoring and control of machines and processes. It is cost effective and easy to install and can be used for program for varieties of applications for industrial, agricultural and building automation.

Integrated Ethernet port for program read and write and ModbusTCP master slave function

Can use a SD card as an external memory card to read and write user program and configuration files

Password protection function can be set for two levels A and B
