Siemens 3SE5 Series Safety Switch, 1 NO/1 NC, IP67, IP66, Metal Housing, 400V, 6A

RS庫存編號:: 768-6474
Distrelec 貨號:: 136-30-846
製造零件編號:: 3SE5112-0CA00
製造商:: Siemens

Siemens 3SE5 Series Safety Switch, 1 NO/1 NC, IP67, IP66, Metal Housing, 400V, 6A

小計（1 件）*

TWD4,057.00

(不含稅)

TWD4,259.85

訂單超過 $1,300.00 免費送貨

有庫存

18 件準備從其他地點送貨

**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。

單位	每單位
1 +	TWD4,057.00

* 參考價格

RS庫存編號:: 768-6474
Distrelec 貨號:: 136-30-846
製造零件編號:: 3SE5112-0CA00
製造商:: Siemens

規格

產品概覽和技術數據資料表

法例與合規

產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	Siemens
	Product Type	Safety Switch
	IP Rating	IP67, IP66
	Contact Configuration	1 NO/1 NC
	Housing Material	Metal
	Contact Type	Snap Action
	Terminal Type	Screw
	Switching Current	6A
	Series	3SE5
	Switching AC Voltage	400V
	Minimum Operating Temperature	-25°C
	Maximum Operating Temperature	85°C
	Length	40.5mm
	Depth	78mm
	Standards/Approvals	UL, RoHS, IEC, EAC, CSA, CE, CCC
	Width	37.3mm
	Hazardous Area Certification	No
	Mechanical Life	15000000Cycles
	Conduit Entry	M20 x 1.5
	Mounting Orientation	Universal
	Operating Force	20N

	選取全部
	品牌 Siemens
	Product Type Safety Switch
	IP Rating IP67, IP66
	Contact Configuration 1 NO/1 NC
	Housing Material Metal
	Contact Type Snap Action
	Terminal Type Screw
	Switching Current 6A
	Series 3SE5
	Switching AC Voltage 400V
	Minimum Operating Temperature -25°C
	Maximum Operating Temperature 85°C
	Length 40.5mm
	Depth 78mm
	Standards/Approvals UL, RoHS, IEC, EAC, CSA, CE, CCC
	Width 37.3mm
	Hazardous Area Certification No
	Mechanical Life 15000000Cycles
	Conduit Entry M20 x 1.5
	Mounting Orientation Universal
	Operating Force 20N

登入下載 CAD 模型

COO (Country of Origin):: DE

Siemens 3SE5 Series Safety Switch, 20N Operating Force, 400V Switching Voltage - 3SE5112-0CA00

This safety switch is a mechanical interlock device designed for industrial access protection and position monitoring. Housed in a metal enclosure with M20 x1.5 conduit entry, it provides positive-opening snap-action contacts for safety-related applications. The unit operates across a wide ambient range and is suitable for environments requiring robust ingress protection and routine cyclic operation.

Features and Benefits:

• IP66/IP67-rated enclosure for harsh environmental protection
• Positive-opening contact mechanism for safety-compliant interruption
• 15 000 000 mechanical cycles for extended operational lifespan
• 20N minimum actuating force for predictable actuation behaviour
• Screw Terminal connection enabling secure electrical termination

Applications

• Suitable for machine-guard interlock monitoring in manufacturing
• Used with conveyor access doors requiring positive-opening switch
• Ideal for panels needing a Compact metal-housed safety device
• Can be used for guarding systems exposed to dust and water
• Suitable for installations requiring an M20 conduit entry point

What is the rated insulation voltage for the device?

The insulation rating is 400V, supporting typical industrial control voltages.

How does the unit perform under mechanical stress?

It withstands shock of 30g/11ms and vibration of 0.35mm/5g per IEC tests.

What cable entry and conductor types are supported?

A single M20 x1.5 conduit entry is provided and screw terminals accept solid 0.5…1.5mm² and 2x0.5…0.75mm² conductors.

What are the thermal and storage limits for use and transport?

Operational temperature range is -25°C…+85°C and storage range is -40°C…+90°C.
