Omron SHL Series Plunger Limit Switch, SPDT, IP67, Zinc Housing, 125V, 2A

RS庫存編號:: 214-7957
製造零件編號:: SHL-Q2255-01
製造商:: Omron

Omron SHL Series Plunger Limit Switch, SPDT, IP67, Zinc Housing, 125V, 2A

小計（1 件）*

TWD1,471.00

(不含稅)

TWD1,544.55

訂單超過 $1,300.00 免費送貨

有庫存

4 件準備從其他地點送貨
加上 20 件從 2026年10月12日起發貨

**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。

單位	每單位
1 +	TWD1,471.00

* 參考價格

RS庫存編號:: 214-7957
製造零件編號:: SHL-Q2255-01
製造商:: Omron

規格

產品概覽和技術數據資料表

法例與合規

產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	Omron
	Product Type	Limit Switch
	Actuator Type	Plunger
	IP Rating	IP67
	Contact Configuration	SPDT
	Housing Material	Zinc
	Contact Type	Snap Action
	Switching Current	2A
	Terminal Type	Molded Terminal
	Series	SHL
	Switching AC Voltage	125V
	Minimum Operating Temperature	-10°C
	Maximum Operating Temperature	80°C
	Standards/Approvals	CSA, UL
	Width	36mm
	Length	72.5mm
	Depth	17.5mm
	Hazardous Area Certification	No
	Mechanical Life	10000000Operations
	Operating Force	9.81N
	Mounting Orientation	Side

	選取全部
	品牌 Omron
	Product Type Limit Switch
	Actuator Type Plunger
	IP Rating IP67
	Contact Configuration SPDT
	Housing Material Zinc
	Contact Type Snap Action
	Switching Current 2A
	Terminal Type Molded Terminal
	Series SHL
	Switching AC Voltage 125V
	Minimum Operating Temperature -10°C
	Maximum Operating Temperature 80°C
	Standards/Approvals CSA, UL
	Width 36mm
	Length 72.5mm
	Depth 17.5mm
	Hazardous Area Certification No
	Mechanical Life 10000000Operations
	Operating Force 9.81N
	Mounting Orientation Side

Datasheet-SHL-Q2255-01

登入下載 CAD 模型

Omron SHL Series Limit Switch, 10A Maximum Current, IP67 - SHL-Q2255-01

This limit switch offers efficient operation for various automation applications. With its robust construction and a reliable snap action mechanism, it ensures precise control in industrial environments where safety and performance are critical.

Features & Benefits

• IP67 rating provides protection against dust and moisture

• Configured as SPDT to cater to various switching requirements

• Features a plunger actuator for improved usability

• Snap action design enables quick response time

• Rated for a maximum current of 10A for demanding tasks

• Terminal block connection facilitates easy installation

Applications

• Suitable for safety circuits in industrial equipment

• Employed in packaging and material handling processes

• Applicable in lift and hoist control systems

How do I install the switch for optimal performance?

Secure the switch to a stable surface and connect the terminal block according to the circuit requirements, ensuring that both the normally closed and normally open contacts are correctly wired.

What is the maximum voltage this switch can handle?

This switch can manage a maximum AC voltage of 125V, making it applicable for a range of standard electrical operations in industrial settings.

What maintenance is required to ensure longevity?

Regular inspections for any physical damage and securing all connections will help maintain performance and extend the product's lifespan.
