McLennan Servo Supplies Ovoid Gearbox, 25:2 Gear Ratio, 0.45 Nm Maximum Torque, 400rpm Maximum Speed
- RS庫存編號:
- 336-450
- 製造零件編號:
- P5-G06L82
- 製造商:
- McLennan Servo Supplies
小計（1 件）*
TWD1,591.00
(不含稅)
TWD1,670.55
(含稅)
訂單超過 $1,300.00 免費送貨
有庫存
- 4 件準備從其他地點送貨
**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。
單位 | 每單位 |
|---|---|
| 1 + | TWD1,591.00 |
* 參考價格
- RS庫存編號:
- 336-450
- 製造零件編號:
- P5-G06L82
- 製造商:
- McLennan Servo Supplies
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | McLennan Servo Supplies | |
| Product Type | Gearbox | |
| Gear Ratio | 25:2 | |
| Gearbox Type | Ovoid | |
| Maximum Output Torque | 0.45Nm | |
| Shaft Diameter | 4mm | |
| Diameter | 49.2 mm | |
| Overall Length | 62.8mm | |
| Overall Width | 47.6mm | |
| Overall Depth | 16.5 mm | |
| Maximum Speed | 400rpm | |
| Standards/Approvals | No | |
| Series | P5 | |
| Efficiency | 80% | |
| 選取全部 | ||
|---|---|---|
品牌 McLennan Servo Supplies | ||
Product Type Gearbox | ||
Gear Ratio 25:2 | ||
Gearbox Type Ovoid | ||
Maximum Output Torque 0.45Nm | ||
Shaft Diameter 4mm | ||
Diameter 49.2 mm | ||
Overall Length 62.8mm | ||
Overall Width 47.6mm | ||
Overall Depth 16.5 mm | ||
Maximum Speed 400rpm | ||
Standards/Approvals No | ||
Series P5 | ||
Efficiency 80% | ||
Precision Instrument Gearboxes
High quality ovoid gearboxes
Precision cut metal gear system
Ideal for scientific instrumentation, medical and process control equipment
Supplied with
fitting instructions, screws for mounting the motor plus a pinion which may be easily fitted to the motor spindle using high strength retainer stock no. 473-417 (not supplied) and the pacer tool provided.
