Yamaichi 2.54mm Pitch 8 Way, SMT Turned Pin IC Dip Socket
- RS庫存編號:
- 240-5927
- 製造零件編號:
- IC26V-0803-GG4
- 製造商:
- Yamaichi
可享批量折扣
小計（1 件）*
TWD53.00
(不含稅)
TWD55.65
(含稅)
訂單超過 $1,300.00 免費送貨
有庫存
- 69 件準備從其他地點送貨
- 加上 52 件從 2026年3月16日 起發貨
**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。
單位 | 每單位 |
|---|---|
| 1 - 4 | TWD53.00 |
| 5 - 14 | TWD52.00 |
| 15 - 49 | TWD51.00 |
| 50 - 99 | TWD50.00 |
| 100 + | TWD47.00 |
* 參考價格
- RS庫存編號:
- 240-5927
- 製造零件編號:
- IC26V-0803-GG4
- 製造商:
- Yamaichi
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | Yamaichi | |
| Number of Contacts | 8 | |
| Mounting Type | Surface Mount | |
| Pin Type | Turned | |
| Pitch | 2.54mm | |
| Row Width | 0.3in | |
| 選取全部 | ||
|---|---|---|
品牌 Yamaichi | ||
Number of Contacts 8 | ||
Mounting Type Surface Mount | ||
Pin Type Turned | ||
Pitch 2.54mm | ||
Row Width 0.3in | ||
- COO (Country of Origin):
- PH
The Yamaichi IC26V Series DIP is highly reliable four point contact design. It has machined sleeves eliminating solder or flux penetration. It stand-off preventing blowholes in solder joints. The plating of inner contact and of solder terminal are of gold. They have a operating temperature of -65 to +125 degree Celsius and current Rating of 1A.
RoHS compliant
No. of contact - 8
Insulation Resistance - 1000M ohm
Withstanding voltage - 700VAC rms/minute
Contact Resistance - 20M ohm max
No. of contact - 8
Insulation Resistance - 1000M ohm
Withstanding voltage - 700VAC rms/minute
Contact Resistance - 20M ohm max
