Molex Barrier Strip, 2 Contact, 9.53mm Pitch, 1 Row, 25A, 300 V
- RS庫存編號:
- 144-8092
- 製造零件編號:
- 387207502
- 製造商:
- Molex
當前暫無庫存，可於19/09/2024發貨，6 工作日送達。
已增加
單價（不含稅） 個
TWD62.90
(不含稅)
TWD66.04
(含稅)
| 單位 | Per unit | Per Tray* |
| 1100 - 4400 | TWD62.90 | TWD69,190.00 |
| 5500 + | TWD61.00 | TWD67,100.00 |
| * 參考價格 | ||
- RS庫存編號:
- 144-8092
- 製造零件編號:
- 387207502
- 製造商:
- Molex
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
This Product Specification covers the 9.53 mm (.375 inch) centerline (pitch) printed circuit board (PCB) terminal block series with tin plating.
9.53mm Pitch Beau PCB Terminal Strip, without Mounting Ends, 2 Circuits, with Screw Clamp Washer
規格
屬性 | 值 |
|---|---|
| Number of Contacts | 2 |
| Pitch | 9.53mm |
| Body Orientation | Straight |
| Contact Material | Brass |
| Contact Plating | Tin |
| Number of Rows | 1 |
| Screw Size | M3 |
| Wire Size | 22 → 12 AWG |
| Material | PBT |
| Current Rating | 25A |
| Voltage Rating | 300 V |
| Dimensions | 21.1 x 15.7 x 16.8mm |
| Depth | 16.8mm |
| Length | 21.1mm |
| Minimum Operating Temperature | -40°C |
| Width | 15.7mm |
| Maximum Operating Temperature | +100°C |
