Pneumatic Separators

Pneumatic separators, commonly also called water separators, are pneumatic air preparation devices used to remove water or mist from pneumatic systems. They can also act as filters to remove any unwanted – sometimes harmful – contaminants from the system, such as dust particles.

Why use pneumatic separators?

Pneumatic separators are an important part of keeping a pneumatic or compressed air system running smoothly. Failure to remove moisture the system can result in condensation in piping, pneumatic tools and instruments, leading to damage and premature failure.

Condensed water can cause corrosion to the storage and distribution system, as well as damage to production machinery and your application's end products. Liquid water can also wash away pre-lubricants on cylinders and valves, decreasing their operational life. Water in a pneumatic system also reduces production efficiency and increases maintenance costs.

Features and benefits of pneumatic separators

Features and benefits of pneumatic separators may include:

  • Lightweight design that is easy to install and adjust
  • Automatic drain, meaning no maintenance
  • Resistance to clogging

...
顯示內容 隱藏內容

篩選條件

正在檢視 1 - 20,共 46 項產品
Results per page
Description Price Manufacturer Series Typical Flow Typical Flow Rated At Port Connection Filtration Size Element Material Port Connection Thread Size Minimum Operating Temperature Maximum Operating Temperature Maximum Operating Pressure Port Connection Thread Standard Minimum Operating Pressure
RS庫存編號 244-5332
製造零件編號AMG350C-F04D
BrandSMC
TWD7,386.00
單位
AMG 1500 L/min 0.7MPa G 1/2 - Resin 1/2 in +5°C +60°C 1.5 MPa G 0.15MPa
RS庫存編號 783-2053
製造零件編號AFM40-F04D-A
BrandSMC
TWD3,624.00
單位
AFM 1100 L/min 0.7MPa G 1/2 0.3µm - 1/2 in -5°C +60°C 1 MPa, 1.5 MPa G 0.1MPa
RS庫存編號 890-3143
製造零件編號AFM30-F03BD-A
BrandSMC
TWD2,708.00
單位
AFM30 450 L/min - G 3/8 0.3µm - 3/8 in -5°C +60°C 1 MPa G 0.05MPa
RS庫存編號 202-3280
製造零件編號MS9-LWS-G-U-V
BrandFesto
TWD14,001.00
單位
MS 25 l/sec 2 → 12bar - 9µm - - - - - - -
RS庫存編號 783-1927
製造零件編號AFD30-F03-A
BrandSMC
TWD2,315.00
單位
AFD 240 L/min 0.7MPa G 3/8 0.01µm - 3/8 in -5°C +60°C 1 MPa, 1.5 MPa G 0.05MPa
RS庫存編號 715-0720
製造零件編號AMG150C-F02D
BrandSMC
TWD4,219.00
單位
AMG 300 L/min 0.7MPa G 1/4 - Resin 1/4 in +5°C +60°C 1.5 MPa G 0.1MPa
RS庫存編號 783-1983
製造零件編號AFM20-F02C-A
BrandSMC
TWD1,875.00
單位
AFM 200 L/min 0.7MPa G 1/4 0.3µm - 1/4 in -5°C +60°C 1 MPa, 1.5 MPa G 0.1MPa
全新
RS庫存編號 218-1004
製造零件編號SPC 155
BrandPREVOST
TWD5,269.00
單位
SPC 43 l/sec. 16bar G 1/2 - - 1/2 - - - - -
RS庫存編號 202-3191
製造零件編號MS6-LWS-1/2-U-V
BrandFesto
TWD9,896.00
單位
MS 63.33 l/sec 2 → 12bar G 1/2 6µm - 0.5 - - - G -
RS庫存編號 783-1955
製造零件編號AFD40-F04D-A
BrandSMC
TWD3,693.00
單位
AFD 600 L/min 0.7MPa G 1/2 0.01µm - 1/2 in -5°C +60°C 1 MPa, 1.5 MPa G 0.1MPa
RS庫存編號 827-2082
製造零件編號AFM20-N02-CZ
BrandSMC
TWD1,369.00
單位
AFM 200 L/min 0.7MPa NPT 1/4 0.3µm - 1/4 in -5°C +60°C 1 (Operating) MPa, 1.5 (Proof) MPa NPT 0.05MPa
RS庫存編號 715-0717
製造零件編號AM150C-F02D-T
BrandSMC
TWD3,897.00
單位
AM 300 L/min 0.7MPa G 1/4 - Glass Fibre 1/4 in +5°C +60°C 1.5 MPa G 0.1MPa
RS庫存編號 783-1930
製造零件編號AFD30-F03C-A
BrandSMC
TWD2,747.00
單位
AFD 240 L/min 0.7MPa G 3/8 0.01µm - 3/8 in -5°C +60°C 1 MPa, 1.5 MPa G 0.1MPa
全新
RS庫存編號 218-1003
製造零件編號SPC 1280
BrandPREVOST
TWD15,747.00
單位
SPC 355 l/sec. 16bar G 2 - - 2 - - - - -
RS庫存編號 783-2062
製造零件編號AFM40-F06-A
BrandSMC
TWD3,027.00
單位
AFM 1100 L/min 0.7MPa G 3/4 0.3µm - 3/4 in -5°C +60°C 1 MPa, 1.5 MPa G 0.05MPa
RS庫存編號 826-8169
製造零件編號AMG150C-N02BC
BrandSMC
TWD4,572.00
單位
AMG 300 L/min - NPT 1/4 - Resin 1/4 in +5°C +60°C 1 MPa, 1.5 MPa NPT 0.05MPa
RS庫存編號 890-3130
製造零件編號AFM30-F02-A
BrandSMC
TWD2,178.00
單位
AFM30 450 L/min - G 1/4 0.3µm - 1/4 in -5°C +60°C 1 MPa G 0.05MPa
RS庫存編號 783-1933
製造零件編號AFD30-F03D-A
BrandSMC
TWD2,747.00
單位
AFD 240 L/min 0.7MPa G 3/8 0.01µm - 3/8 in -5°C +60°C 1 MPa, 1.5 MPa G 0.1MPa
RS庫存編號 783-1889
製造零件編號AFD20-F01-A
BrandSMC
TWD1,853.00
單位
AFD 120 L/min 0.7MPa G 1/8 0.01µm - 1/8 in -5°C +60°C 1 MPa, 1.5 MPa G 0.05MPa
RS庫存編號 783-1924
製造零件編號AFD30-F02D-A
BrandSMC
TWD2,747.00
單位
AFD 240 L/min 0.7MPa G 1/4 0.01µm - 1/4 in -5°C +60°C 1 MPa, 1.5 MPa G 0.1MPa
