- RS庫存編號:
- 256-0843
- 製造零件編號:
- 6GK19050EC00
- 製造商:
- Siemens
當前暫無庫存,可於24/05/2024發貨,6 工作日送達。
已增加
單價(不含稅) 個 (每包:5個)
TWD873.00
(不含稅)
TWD916.65
(含稅)
單位 | Per unit | Per Pack* |
5 + | TWD873.00 | TWD4,365.00 |
* 參考價格 |
- RS庫存編號:
- 256-0843
- 製造零件編號:
- 6GK19050EC00
- 製造商:
- Siemens
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- DE
產品詳細資訊
Siemens Circular Connector, Metal Enclosure, 40g Weight - 6GK Series - 6GK19050EC00
Put your industrial data hub in touch with equipment using this circular connector from Siemens. The durable plug ensures components in an automated system receive data and power to keep your setup running reliably and efficiently. As it's a pre-built assembly, you simply hook it up to a cable and you're set to go. Its screwed joint locking mechanism makes a secure connection, so there's minimal risk of the plug working loose. Resistance to water means you can count on this product's longevity in humid operating conditions. Choose a circular connector like this one for robotic equipment on automated assembly lines.
Features & Benefits
Integrated strain relief reduces the risk of it breaking away from a cable
IP65-rated housing that's dust-tight and protected against nozzle-projected water
Compatible with harsh environments, thanks to its broad operating temperature range between -40°C and +70°C
Light weight of 40g puts minimal dragging strain on cables
IP65-rated housing that's dust-tight and protected against nozzle-projected water
Compatible with harsh environments, thanks to its broad operating temperature range between -40°C and +70°C
Light weight of 40g puts minimal dragging strain on cables
Does this circular connector include a resistor?
Yes, the product features an integrated resistor that keeps your power supply stable by ensuring there's minimal risk of interference at your plug point.
規格
屬性 | 值 |
---|---|
Number of Contacts | 5 |
Connector Size | M12 |
Plug/Socket | Plug |
Contact Gender | Male |
Termination Method | Cable |
IP Rating | IP65, IP67 |
Series | 6GK |
Coding | B |
Housing Material | Metal |
Strain Relief | Yes |
Maximum Operating Temperature | +70°C |
Minimum Operating Temperature | -40°C |
