    Sanyo Denki San Ace 9WP Series Axial Fan, 12 V dc, DC Operation, 74.5m³/h, 1.68W, IP68, 92 x 92 x 25mm

    RS庫存編號:
    829-8965
    製造零件編號:
    9WP0912F401
    製造商:
    Sanyo Denki
    Sanyo Denki
    查看所有Axial Fans
    38 現貨庫存,可於6工作日發貨。
    Add to Basket
    單位

    已增加

    單價(不含稅) 個

    原價 TWD1,074.00

    您付款

    TWD864.00

    (不含稅)

    TWD907.20

    (含稅)

    單位Per unit
    1 - 4TWD864.00
    5 - 11TWD838.00
    12 - 24TWD812.00
    25 - 49TWD795.00
    50 +TWD777.00
    RS庫存編號:
    829-8965
    製造零件編號:
    9WP0912F401
    製造商:
    Sanyo Denki
    COO (Country of Origin):
    PH

    產品概覽和技術數據資料表


    法例與合規

    COO (Country of Origin):
    PH

    產品詳細資訊

    San Ace IP68 Waterproof DC Fans - 9WP Series


    San Ace IP68 fans offer protection against dust, water jets and water immersion of up to 1m.

    Encapsulated motor with dual stainless steel ball bearing
    Long life of 86,000 hrs (60/80mm) / 65,000 hrs (92/119mm) at 40°C ambient temp
    3rd wire pulse sensor for fan status monitoring open collector two pulses per revolution
    Lightweight plastic construction
    Motor protection system lock rotor and reverse polarity

    Sanyo Denki Axial Fan, 12V DC, 30dB - San Ace 9WP Series - 9WP0912F401


    Use this axial fan from Sanyo Denki to keep your electronic components ventilated for optimal performance. Thanks to its high speed of 2650rpm, this device provides a powerful air flow of 74.4m³/h for effective cooling of your machine parts. Its current rating of 0.14A makes it suitable for use in low-power systems. This fan has a wide operating temperature range of -20°C to +70°C for use in demanding environments. Its IP68 rating means it can withstand dust and immersion in 1.5m of water for up to 30 minutes, making it suitable for both indoor and outdoor use.

    Features & Benefits


    • Plastic body and blades for durability and resistance to impact
    • Integrated finger guards to prevent contact with fan blades for optimal safety
    • Low sound pressure level of 30dB for quiet operation in the workplace
    • Self-extinguishing for use in fire-prone areas
    • Voltage rating of 12V DC for use in low-voltage systems

    Applications


    • AC condensers
    • Vending machines
    • Process and packaging industry

    How do I mount this fan?


    This fan is easy to mount. It has 4.5mm holes on its four edges for direct surface mounting using screws.


    規格

    屬性
    Supply Voltage12 V dc
    Height92mm
    AC or DC OperationDC
    Power Consumption1.68W
    Width92mm
    Maximum Current140mA
    Depth25mm
    Dimensions92 x 92 x 25mm
    Termination TypeLead Wire
    Air Flow74.5m³/h
    Noise Level30dB
    Fan Speed2650rpm
    Sensor TypeTachometer
    Bearing TypeBall
    IP RatingIP68
