Festo Compact Air Bellows EB-165-125, 2 convolution , 125mm Stroke
- RS庫存編號:
- 203-1535
- 製造零件編號:
- EB-165-125
- 製造商:
- Festo
當前暫無庫存，可於24/05/2024發貨，6 工作日送達。
已增加
單價（不含稅） 個
TWD18,229.00
(不含稅)
TWD19,140.45
(含稅)
| 單位 | Per unit |
| 1 + | TWD18,229.00 |
- RS庫存編號:
- 203-1535
- 製造零件編號:
- EB-165-125
- 製造商:
- Festo
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- HU
產品詳細資訊
The Festo stroke of the bellows cylinder can be made to carry out a circular path, in which case the indicated tilt angle á must not be exceeded. During setup the minimum height must be observed, and that the maximum height must not be exceeded at any given point. It has 165 size, maintenance-free and no stick/slip effect.
Size 165
Required installation diameter 180 mm
Stroke 125 mm
Max height when extended 200 mm
Max. tipping angle 30 deg
Required installation diameter 180 mm
Stroke 125 mm
Max height when extended 200 mm
Max. tipping angle 30 deg
規格
屬性 | 值 |
|---|---|
| Manufacturer Series | EB-165-125 |
| Nominal Diameter | 180mm |
| Number of Convolutions | 2 |
| Stroke | 125mm |
| Installation Height Minimum | 200mm |
