NMB DDR-1650HHMTRA1P24LY121 Double Row Deep Groove Ball Bearing- Both Sides Shielded 5mm I.D, 16mm O.D
- RS庫存編號:
- 138-635
- 製造零件編號:
- DDR-1650HHMTRA1P24LY121
- 製造商:
- NMB
216 現貨庫存，可於6工作日發貨。
已增加
單價（不含稅） 個 (每包:2個)
原價 TWD404.00
您付款
TWD98.50
(不含稅)
TWD103.42
(含稅)
| 單位 | Per unit | Per Pack* |
| 2 - 98 | TWD98.50 | TWD197.00 |
| 100 - 198 | TWD96.00 | TWD192.00 |
| 200 + | TWD94.50 | TWD189.00 |
| * 參考價格 | ||
- RS庫存編號:
- 138-635
- 製造零件編號:
- DDR-1650HHMTRA1P24LY121
- 製造商:
- NMB
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
Metric & Imperial Bearings - ABEC 5
NMB metric and imperial bearings manufactured to ABEC 5. The bearings are suitable for use with precision instruments, chart recorders, etc. Manufactured from corrosion-resistant steel, the bearings are available in two designs: plain and flanged. The metric and imperial bearings incorporate double metallic protection shields, and the metric plain bearings are also available in Chromium Steel.
規格
屬性 | 值 |
|---|---|
| Inside Diameter | 5mm |
| Outside Diameter | 16mm |
| Race Width | 5mm |
| Ball Bearing Type | Double Row Deep Groove Ball Bearing |
| Sealing Arrangement | Both Sides Shielded |
| Bearing Clearance | CN |
| Material | Steel |
| Ball Material | Stainless Steel |
| Cage Material | Steel |
| Number of Rows | 1 |
| Static Load Rating | 671kN |
| Dynamic Load Rating | 1.735kN |
| Bore Type | Parallel |
| Partial Bearing Code | DDR-1650HH |
| Race Type | Plain |
| Race Material | Martensitic Stainless Steel |
